This document was generated on 10/07/2013
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
Active
1.00mm Pitch DDR2 DIMM Socket, Through Hole, 0.76μm Gold (Au), 3.18mm
Soldertail, 276 Circuits, Lead-Free
Documents:
Agency Certification
CSA
UL
General
Product Family
Series
Component Type
JEDEC Outline
Product Name
UPC
Physical
LR19980
E29179
Memory Module Sockets
Socket
N/A
DDR2 DIMM
822348731893
image - Reference only
ELV and RoHS
Compliant
Contains SVHC: No
Not Low-Halogen
Need more information on product
environmental compliance?
Series
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Entry Angle
Flammability
Function Key
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Temperature Range - Operating
Termination Interface: Style
Electrical
Current - Maximum per Contact
Voltage - Maximum
Voltage Key
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
276
276
Black, Natural
25
Vertical (Top Entry)
94V-0
None
Yes
Brass, Phosphor Bronze
Gold
Tin
High Temperature Thermoplastic
11.380/g
3.18mm
Yes
Yes
2.36mm
Tray
1.00mm
1.00mm
0.762μm
2.540μm
-55°C to +85°C
Through Hole
0.5A
30V AC (RMS)/DC
Center
5
SMC & Wave Capable (TH only)
1
260
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
87775Series
